Card printer
| item | detail | |
|---|---|---|
| Print Technology | Direct-to-card Dye-sublimation / Resin thermal transfer | |
| Print Capabilities | Single & Dual sided printing | |
| Additional hopper for the 2nd type of cards or the extended | ||
| Full-color and monochrome printing capability | ||
| Alphanumeric text, logos and digitized signatures | ||
| Print Resolution | 300 dpi (11.8 dpm), 16.7 Million Color | |
| Print Speed | Full-color Printing | |
| Single Side (YMCKO) 180 ~ 200 cards/hour. | ||
| Dual Side (YMCKOK) 140 cards/hour. | ||
| Dual Side (YMCKO) 95 cards/hour. | ||
| Monochrome up to 600 cards/hr. | ||
| Card | Automatic Feed : 100-card input (0.76mm) -up to 200 hopper option | |
| Output hopper: 50-60 cards (0.76mm) | ||
| Manual Single Feed : 1 card input | ||
| Printer Encoding Option |
Magnetic Stripe Encoding | ISO7811 (Track 1,2,3), Coercivity : HiCo/LoCo JIS II |
| Smart Card Personalization | ISO7816, EMV Level 1(PC/SC or Serial) | |
| RF ID Card | Mifare, ISO 14443 A / B, Desfire, NFC, Felica (PC/SC or Serial) | |
| SAM | PLCC 1 (Extra-2 Sockets), SIM 4 sockets | |
| Mobile Chip Card | ISO 7816 | |
| Printer Specifications |
Dimensions | N20/N30 : 366(L) × 184 (W) × 228 (H)mm |
| Weight | N20/N30 : 4.5kg | |
| Power | 100-240V ~ 50/60Hz 1.7A / Output : DC24V 2.5A | |
| Font | True Type Fonts via Window Drivers | |
| Memory | 128MB RAM | |
| Interface | USB2.0 (High-Speed), RS-232, Built in 10/100 Ethernet | |
| Operation System for Printer Driver |
Windows Vista, Windows 7 & 8 & 10 Windows 2003/2008 server | |
| Approvals | FCC Class A, CE (EN 55022 Class A, EN 55024), CCC, KCC Energy STAR EAC RoHS | |
| SECURITY | Kensington ® physical lock slot Hopper lock (N20/N30) - optional Top cover lock (ribbon lock) - optional |
|
| Software | Card Designer 2.0™ for Easy Printing | |
| Limited Warranty | Printer - 2 years Printer Head - 2 years | |
