HD CARD PRINTER
Best solution for desktop ID card printer by POINTMAN own technology.
Print your card in high definition full-color with various features.
| item | detail | |
|---|---|---|
| Print Technology | Dye Sublimation retransfer | |
| Print Capabilities | Single & Dual sided printing | |
| Full-color and monochrome retransfer | ||
| Print Resolution | 300dpi, Y/M/C 256 color per pannel | |
| Card | Type | PVC, Mag.Stripe cards |
| Thickness | 0.8~1.0 | |
| Format | CR79 85.7mm x 52.1mm / 3.303” x 2.051” | |
| CR80 (ISO/IEC7810) 85.6mm x 54mm / 3.375” x 2.125” | ||
| CR90 92.2mm x 60.2mm / 3.63” x 2.37” | ||
| Capacity | 200 input / 150 output | |
| Ribbon | Film Capacity | Clear & Holographic transfer film: 1200 prints/roll |
| Ribbon Capacity | YMCK ribbon : 600 prints/roll | |
| MONO K ribbon : 2400 prints/roll | ||
| Print Speed | Color | YMC Single-side : 24sec per card / 150 cards per hour |
| YMC Dual-side : 50sec per card / 70 cards per hour | ||
| YMCK Single-side : 27sec per card / 130 cards per hour | ||
| YMCK Dual-side : 60sec per card / 60 cards per hour | ||
| Monochrome | MONO K Single-side : 12sec per card / 300 cards per hour | |
| MONO K Dual-side : 30sec per card / 120 cards per hour | ||
| Display | TFT LCD panel, Size : 4 inch, Resolution : 480×320 | |
| Resistive Touchscreen | ||
| Optional | Magnetic Stripe Encoding | ISO 7811 - Track 1/2/3, JIS II |
| Coercivity: HiCo / LoCo | ||
| IC Contact Smart Card Encoding | ISO 7816 and EMV (PC/SC-compliant) | |
| SAM | PLCC 1 (Extra-2 sockets), SIM 4 sockets | |
| RF Contactless Smart Card Encoding | Mifare, Desfire, ISO 14443 A,B, NFC, Felica(PC/SC or Serial) *Other encoders are available upon request. |
|
| Scanner | CIS (300/600 dpi) | |
| Software | Operating System | Windows® 10 / 8.1 / 8 / 7 / Vista® / XP / Server 2012 / Server 2012 R2 / Server 2008 / Server 2008 R2 / Server 2003 |
| Program | Card Designer 2.0 for easy printing | |
| Interface | USB 2.0 connection, 10/100 BASE-T Ethernet | |
| Power | Input | 100-240V 50/60Hz 2.1A |
| Output | DC 24.3V 6.25A | |
| Environmental Operating Range | Sheltered office environment 10°C to 30°C (50°F to 85°F) | |
| Weight | 11.78kg (25.97 lb) | |
| Dimension | With Hopper | 451mm L x 270mm W x 397mm H (17.76” L x 10.63” W x 15.63” H) |
| Without Hopper | 451mm L x 270mm W x 304mm H (17.76” L x 10.63” W x 11.97” H) | |
| Limited Warranty | 2 years | |
