kiosk CaRd PRiNteR
| item | detail | |
|---|---|---|
| Printer | Direct thermal printing | |
| Single & dual | ||
| 300dpi printing resolution | ||
| Full-color and monochrome printing | ||
| Media | Plastic card | Card type: PVC and composite PVC cards |
| Card thickness : 0.76 mm, other thickness upon request | ||
| Card format : ISO CR80 -ISO 7810 (53.98mm x 85.60mm) | ||
| Ribbon | YMCKO ribbon : 200 prints/roll or 250 prints/roll | |
| YMCKOK ribbon : 170 prints/roll | ||
| 1/2ymcKO ribbons : 400 prints/roll | ||
| Mono ribbon (black, silver, gold, white) : 1000 prints/roll | ||
| Printing speed | Full color printing | Single side : more than 150 cards/hour |
| Dual side : more than 100 cards/hour | ||
| Mono printing | 700 cards/hour | |
| Card reject | Ability to retrieve the defective cards and uncollected cards (default reject card bin) |
|
| Optional encoding | Magnetic stripe encoding | ISO7811 (track 1, 2 and 3) Coercivity : Hi-Co & Lo-Co |
| Contact smart card encoding | ISO 7816, EMV Level 1 and PBOC 3.0 (PS/SC, serial) | |
| Contactless smart card encoding | ISO 14443 type A & B, ISO 15693, Mifare * Other type upon request |
|
| Card hopper capacity | Each hopper available with 3 capacities | 150 cards, 300 cards and 500 cards - 0.76mm * other capacity upon request |
| Interface | USB 2.0 | |
| Network (optional) : Built in 10/100 Ethernet | ||
| Driver & software | Operating system | Windows XP, Windows Vista / Window 7 & 8, Windows 2003 / 2008 Server ☞ Microsoft Windows Hardware Quality Labs (WHQL) |
| Software Package | DLL, PCL and test program | |
| Temperature | Operating | 5 ~ 40℃ |
| Storage | -10 ~ 60℃ | |
| Power | TPK-3000 | Input : AC 100 ~ 240V, 50 ~ 60Hz |
| Output : DC 24V, 3.75A | ||
| TPK-4200 | Input : AC 100 ~ 240V, 50 ~ 60Hz | |
| Output : DC 24V, 3.75A | ||
| TPK-4400 | Input : AC 100 ~ 240V, 50 ~6 0Hz | |
| Output : DC 24V, 5A | ||
| TPK-4800 | Input : AC 100 ~ 240V, 50 ~ 60Hz | |
| Output : DC 24V, 7A | ||
| Dimension | Shutter | 599.3(L) x 248.9 (H) x 208.2(W) / 150 pcs |
| 599.3(L) x 358.2 (H) x 208.2(W) / 300 pcs | ||
| 599.3(L) x 510.2 (H) x 208.2(W) / 500 pcs | ||
| Bezel | 593.7(L) x 358.2(H) x 208.2(W) / 300pcs | |
| * Dimension is subject to change depending on the options | ||
| Warranty | 1-year limited warranty. | |
